48V magnetic track light 20mm surface mounted/recessed magnetic light

Description

R26 belt lighting system is a new concept of track light.

- Use a flexible braided belt as a rail, allows free placement of lamps.

- 24V low wattage

- Easy installation

- Belt can be cut into any length as needed

- Multiple luminaire and accessories options

- Smart function: support dimming with DALI/TRIAC/0-10V

- Small package size than regular track rail

Quick Detail

Magnetic track light,

48V magnetic track light;

Braided belt light,

Belt light,

24V belt light

Application

Restaurant/Office/Studio/Library/Home/Villa/Retail Shop/Salon room /renovation decoration /Showroom. etc

Specifications

20mm Lamps
*can be customized in 0-10v or Dali dimmable/can be customized with zigbee system
NO.	Model	PICture	Power	RA	Chip	Voltage	Beam	Size	Qty
1	M203-DFS-300		10w	90	sanan	48V Built-in driver	90°	L305*W22*H43mm	1
2	M203-DFS-600		20w	90	sanan			L605*W22*H43mm	1
3	M203-DFS-900		30w	90	sanan			L905*W22*H43mm	1
4	M203-DFS-1200		40W	90	sanan			L1205*W22*H43mm	1
5	M203-LB-6W		6W	90	sanan		24°/36°	L113*W22*H25mm	1
6	M203-LB-12W		12W	90	sanan			L226*W22*H25mm	1
7	M203-LB-18W		18W	90	sanan			L305*W22*H25mm	1
8	M203-LB-24W		24W	90	sanan			L432*W22*H25mm	1
9	M203-LBP-6W		6W	90	sanan		polarized light	L113*W22*H25mm	1
10	M203-LBP-12W		12W	90	sanan			L226*W22*H25mm	1
11	M203-LBP-18W		18W	90	sanan			L305*W22*H25mm	1
12	M203-LBP-24W		24w	90	sanan			L436*W22*H43mm	1
13	M203-TL1-3W		3W	90	sanan		7/21°	L134*W30*H110	1
14	M203-TL1-5W		5W	90	sanan			L134*W30*H160	1
15	M203-TL1-7w		7W	90	bridgelux		15 /24 /36°	L134*W45*H143	1
16	M203-TL1-12w		12W	90	bridgelux			L134*W45*H183	1
17	M203-TL1-16w		16W	90	bridgelux			L134*W60*H162	1
18	M203-TL1-20W		20W	90	bridgelux			L126.5*W60*H200	1
19	M20-TL2-3W		3W	90	sanan		7/21°	φ30*60	1
20	M20-TL2-5W		5W	90	sanan			φ30*110	1
21	M20-TL2-7w		7W	90	bridgelux		15 /24 /36°	φ45*90	1
22	M20-TL2-12w		12W	90	bridgelux			φ45*130	1
23	M20-TL2-16w		16W	90	bridgelux			φ60*110	1
24	M20-TL2-20W		20W	90	bridgelux			φ60*148	1
25	M203-TL-12W		12w	90	bridgelux		15/24/36°	Ф50*136	1
26	M203-TL-20W		20w	90	bridgelux			Ф62*147	1
27	M203-TL-30W		30w	90	bridgelux			Ф75*148	1
28	M203-DFS-90°		20W	90	sanan		120°	L322*W307*H43mm	1
29	M203-LBF-6w		6w	90	sanan		24°/36°	L113*W22*H55mm	1
30	M203-LBF-12w		12w	90	sanan			L226*W22*H55mm	1
31	M203-DFSF-6W		6w	90	sanan		120°	L113*W22*H55mm	1
32	M203-DFSF-12W		12w	90	sanan			L226*W22*H55mm	1
33	M203-FM-9W		9w	90	bridgelux		15°24°36°	Ф50*220	1
34	M203-BL2		10w	90	sanan		134°	Φ100mm	1
35	M203-BL		10w	90	sanan			Φ100mm	1
36	M203-TB300		6W	90	sanan		120°	φ26*300mm	1
37	M203-TB600		12W	90	sanan			φ26*600mm	1
38	M203-PST-8W		8W	90	bridgelux		15°24°36°	φ42*150*135	1
39	M203-PST-16w(A)		16w	90	bridgelux			φ42*150*135	1
40	M203-PST-16w(B)		16w	90	bridgelux			φ42*259*135	1
41	M203-HD-12W		12W	90	sanan		10°24°	φ50*171*135	1
42	M203-LBF4-12W		12W	90	sanan		15°24°36°	220*16.3*115	1
43	M203-LB2-12W		12W	90	sanan			220*22*43	1
44	M203-MBO-A		12w	90	bridgelux		15°24°36°	L135.5*W100*H135	1
45	M203-MBO-B		12w	90	bridgelux		15°24°36°	L135.5*W100*H1000	1

Competitive Advantage

Flexible belt

24V Low Voltage

Lights in stock, fast delivery in 2 weeks

Belt can be cut as needed

Easy installation

Free placement of luminaires
